Technical Specifications | |
Camera | |
Image sensor | 1/2.7”, 4.0 megapixel Progressive scan, CMOS |
Lens | 2.8 mm, F1.6, Fixed iris Horizontal field of view 107.8? Vertical field of view 57? |
DORI distance | Detect : 63 m Observe : 25.2 m Recognize : 12.6 m Identify : 6.3 m |
Day and night | IR-cut filter with auto switch (ICR) |
Minimum illumination | Color: 0.003 Lux (F1.6, AGC ON) 0 Lux with IR |
Shutter time | 1 to 1/100000 sec |
IR illumination | Smart IR, 850nm wavelength Maximum distance up to 50 meters |
Wide dynamic range (WDR) | 120 dB |
Camera angle adjustment | Pan 0? to 360? Tilt 0? to 75? Rotation 0? to 360? |
Video | |
Maximum resolution | 2688 x 1520 |
Multi-streaming | 3 Streams |
Frame rate | Main Stream 4MP (2688 x 1520), Max 30 fps 4MP (2560 x 1440), Max 25 fps Sub Stream 1080P (1920 x 1080), Max 30 fps Third Stream D1 (720 x 576), Max 30 fps |
Video compression | Ultra 265, H.265, H.264 (Baseline/Main/ High Profile), MJPEG |
Video bit rate | CBR/VBR, 128 Kbps~16 Mbps |
Audio | |
Audio streaming | Audio in |
Audio compression | G.711U, G.711A, 8 kHz sampling rate |
Suppression | Supported |
Image | |
White balance | Auto/Outdoor/Fine Tune/Sodium Lamp/ Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Backlight compensation (BLC) | On/Off |
Highlight compensation (HLC) | On/Off |
Image defogging | Digital defog |
Image dewarping | Supported |
Image rotation | Normal/Vertical/Horizontal/180?/ 90?Clockwise/90?Anti-clockwise including Corridor Format (9:16) |
OSD | Up to 8 OSDs |
Privacy mask | Up to 8 areas |
Region of interest (ROI) | Up to 8 areas |
Motion detection | Up to 4 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
Compatible integration | ONVIF? Profile G, ONVIF? Profile S and ONVIF? Profile T, API |
Security | IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication |
Interface | |
Network | 1 x RJ45 10/100M Base-TX Ethernet |
Audio input | - |
Audio output | - |
Alarm input/output | - |
Built-in Mic | Supported |
Reset button | - |
General | |
Ingress protection | IP67 |
Impact resistance | - |
Material | Metal |
Edge storage | Micro SD card up to 256GB ANR (Automatic Network Replenishment) NAS (NFS) |
Operating conditions | -40?C to 60?C (-40?F to 140?F) Humidity: ?95% RH (non-condensing) |
Storage conditions | -40?C to 70?C (-40?F to 158?F) Humidity: ?95% RH (non-condensing) |
Power | Power over Ethernet (PoE) IEEE 802.3af DC 12V?25%, max 4.4 W |
Surge protection | 2 kV |
Dimension (? x H) | ? 110.5 x 94.1 mm (? 4.35” x 3.7”) |
Net weight | 0.43 kg (0.94 lb) |
