Technical Specifications | |
Camera | |
Image sensor | 1/2.7”, 8.0 megapixel Progressive scan, CMOS |
Lens | 2.8 mm, F2.0, Fixed iris Horizontal field of view 112.4? Vertical field of view 60.1? |
DORI distance | Detect : 84 m Observe : 33.6 m Recognize : 16.8 m Identify : 8.4 m |
Day and night | IR-cut filter with auto switch (ICR) |
Minimum illumination | Color: 0.01 Lux (F2.0, AGC ON) 0 Lux with IR |
Shutter time | 1 to 1/100000 sec |
IR illumination | Smart IR, 850nm wavelength Maximum distance up to 30 meters |
Wide dynamic range (WDR) | 120 dB |
Video | |
Maximum resolution | 3840 x 2160 |
Multi-streaming | 3 Streams |
Frame rate | Main Stream 8MP (3840 x 2160), Max 20 fps Sub Stream 1080P (1920 x 1080), Max 30 fps Third Stream D1 (720 x 576), Max 30 fps |
Video compression | Ultra 265, H.265, H.264 (Baseline/Main/ High Profile), MJPEG |
Video bit rate | CBR/VBR, 128 Kbps~16 Mbps |
Audio | |
Audio compression | G.711, 8 kHz sampling rate |
Two-way audio | Supported |
Suppression | Supported |
Image | |
White balance | Auto/Outdoor/Fine Tune/Sodium Lamp/ Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Backlight compensation (BLC) | On/Off |
Highlight compensation (HLC) | On/Off |
Image defogging | Digital defog |
Image dewarping | Supported |
Image rotation | Normal/Vertical/Horizontal/180?/ 90?Clockwise/90?Anti-clockwise including Corridor Format (9:16) |
OSD | Up to 8 OSDs |
Privacy mask | Up to 4 areas |
Region of interest (ROI) | Up to 8 areas |
Motion detection | Up to 4 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, SNMP, HTTPS, SMTP, SSL |
Compatible integration | ONVIF? Profile G, ONVIF? Profile S and ONVIF? Profile T, API |
Security | IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication |
Interface | |
Network | 1 x RJ45 10/100M Base-TX Ethernet |
Built-in Mic | Supported |
Built-in Speaker | - |
Alarm light | - |
Reset button | - |
General | |
Ingress protection | IP67 |
Impact resistance | - |
Material | Metal |
Edge storage | Micro SD card up to 256GB ANR (Automatic Network Replenishment) NAS (NFS) |
Operating conditions | -30?C to 60?C (-22?F to 140?F) Humidity: ?95% RH (non-condensing) |
Storage conditions | -30?C to 70?C (-22?F to 158?F) Humidity: ?95% RH (non-condensing) |
Power | Power over Ethernet (PoE) IEEE 802.3af DC 12V?25%, max 5 W |
Surge protection | 2 kV |
Dimension (? x H) | ? 110.5 x 94.1 mm (? 4.4” x 3.7”) |
Net weight | 0.44 kg (0.97 lb) |
