Technical Specifications
Video and Audio Input
Analog camera input 16 channel BNC
IP camera input 8 channel (only IP up to 24 channel) each channel resolution up to 4K
Video input bandwidth 72 Mbps
Video forwarding bandwidth 80 Mbps
Audio input 1 channel; RCA
Video and Audio Output
Video interface 1 x HDMI, 1 x VGA, 1 x BNC
HDMI output resolution 3840x2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz,
1024x768/60Hz
VGA output resolution 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Audio output 1 channel; RCA
Decoding Performance
Recording resolution 8MP (4K) / 5MP / 4MP / 3MP / 1080P / 960P / 720P / D1 / 4CIF / CIF
Video compression Ultra265, H.265, H.264
Synchronous playback 16 channel
Network management
Network protocols TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Max user access 128 users
Harddisk
HDD installation Support 2 HDDs; SATAIII, up to 6TB capacity for each HDD
Video Content Analytics (VCA)
VCA detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection,
Scene change detection, Auto tracking, Object left behind, Object removed, Heatmap
VCA search Face search, Behavior search
Statistical Analysis People counting
Face recognition
(with face capture camera)
4 channel
Face recognition (with normal camera) 1 channel
Face library capacity Up to 16 face libraries, total capacity of 100,000 face images
External Interface
Network interface 1 x RJ45 10/100/1000 Mbps self-adaptive ethernet interface
Serial interface 1 x RS485
USB interface Rear panel: 1 x USB2.0, 1 x USB3.0
Alarm input/output 4 input, 1 output

General
Power supply 12V DC
Power consumption ?12 W (without HDD)
Working environment -10?C to 55?C (-14?F to 131?F)
Humidity ? 90% RH (non-condensing)
Dimensions (W ? D ? H) 380 ? 318 ? 53.5 mm (15” ? 12.5” ? 2.1”)
Weight (without HDD) ?2 kg (4.41 lb)
