Technical Specifications
Camera
Image sensor 1/2.7”, 2.0 megapixel
Progressive scan, CMOS
Lens 2.8 mm, F2.0, Fixed iris
Horizontal field of view 112.7? Vertical field of view 60.1?

DORI distance Detect : 42 m
Observe : 16.8 m
Recognize : 8.4 m
Identify : 4.2 m

Day and night IR-cut filter with auto switch (ICR)
Minimum illumination Color: 0.02 Lux (F2.0, AGC ON)

0 Lux with IR
Shutter time 1 to 1/100000 sec
IR illumination Smart IR, 850nm wavelength
Maximum distance up to 30 meters

Wide dynamic range (WDR) 120 dB
Video
Maximum resolution 1920 x 1080
Multi-streaming 2 Streams
Frame rate Main Stream

1080P (1920 x 1080), Max 30 fps
Sub Stream
720P (1280 x 720), Max 30 fps
Video compression Ultra 265, H.265, H.264 (Baseline/Main/

High Profile), MJPEG
Video bit rate CBR/VBR, 128 Kbps~16 Mbps
White balance Auto/Outdoor/Fine Tune/Sodium Lamp/

Locked/Auto2
Digital noise reduction 2D/3D DNR
Backlight compensation (BLC) On/Off
Highlight compensation (HLC) On/Off
Image defogging Digital defog
Image dewarping Supported
Image rotation Normal/Vertical/Horizontal/180?
OSD Up to 4 OSDs
Privacy mask Up to 4 areas

133001 JARTON Network Camera

Region of interest (ROI) Up to 8 areas
Motion detection Up to 4 areas
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP,
RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP,
UPnP, HTTP, HTTPS, SMTP, SSL
Compatible integration ONVIF? Profile G, ONVIF? Profile S and

ONVIF? Profile T, API
Security IP address filtering, Access policy,
ARP protection, RTSP authentication,
User authentication

Interface
Network 1 x RJ45 10/100M Base-TX Ethernet
Built-in Mic -
Reset Button -
General
Ingress protection IP67
Impact resistance -
Material Metal
(Sun shield : plastic)
Edge storage Micro SD card up to 128GB
ANR (Automatic Network Replenishment)
Operating conditions -35?C to 60?C (-31?F to 140?F)
Humidity: ?95% RH (non-condensing)
Storage conditions -35?C to 60?C (-31?F to 140?F)
Humidity: ?95% RH (non-condensing)
Power Power over Ethernet (PoE) IEEE 802.3af
DC 12V?25%, max 4.5 W

Surge protection 2 kV
Dimension (L ? W ? H) 165 ? 63.1 ? 62.5 mm (6.5” ? 2.5” ? 2.5”)
Net weight 0.45 kg (0.99 lb)
